Camera
|
|
Image Sensor:
|
1/3" progressive scan CMOS
|
|
Effective Pixels:
|
2560(H)×1440(V)
|
|
Signal System:
|
PAL/NTSC
|
|
Minimum Illumination:
|
Color: 0.005 Lux @(F1.6, AGC ON)
|
|
B/W: 0.001 Lux @(F1.6, AGC ON)
|
|
0 Lux with IR
|
|
White Balance:
|
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
|
|
AGC:
|
Auto/Manual
|
|
HLC:
|
Support
|
|
WDR:
|
120dB
|
|
Shutter Time:
|
50Hz: 1/1 s to 1/30,000 s
|
|
60Hz: 1/1 s to 1/30,000 s
|
|
Day& Night:
|
ICR
|
|
Digital Zoom:
|
16×
|
|
Privacy Masking:
|
24 privacy masks programmable
|
|
Auto Focus:
|
Auto / Semi-automatic / Manual
|
|
Lens
|
|
Focal Length:
|
2.8 to 12mm, 4× optical zoom
|
|
Zoom Speed:
|
Approx. 2s (optical lens, wide-tele)
|
|
Angle of View:
|
Horizontal field of view: 100° to 33° (Wide-Tele)
|
|
Vertical field of view: 53° to 18° (Wide-Tele)
|
|
Diagonal field of view: 119° to 37.5° (Wide-Tele)
|
|
Minimum Working Distance:
|
10 to 1500mm (wide-tele)
|
|
Aperture Range:
|
F1.6 to F2.7
|
|
Pan & Tilt
|
|
Pan Range:
|
0° to 330°
|
|
Pan Speed:
|
Configurable, from 0.1°/s to 100°/s,
|
|
Preset speed: 100°/s
|
|
Tilt Range:
|
Tilt: 0°~90°
|
|
Tilt Speed:
|
Configurable, from 0.1°/s to 100°/s
|
|
Preset Speed: 100°/s
|
|
Proportional Zoom:
|
Rotation speed can be adjusted automatically according to zoom multiples
|
|
Number of Preset:
|
300
|
|
Power-off Memory:
|
Support
|
|
Infrared
|
|
IR irradiation distance:
|
20m
|
|
IR irradiation angle:
|
Adjustable by zoom
|
|
Input & Output
|
|
Audio Input:
|
1-ch audio input
|
|
Audio Output:
|
1-ch audio output
|
|
Network
|
|
Ethernet:
|
10Base -T, /100Base-TX, RJ45 Connector
|
|
Max.Image Resolution:
|
2560 × 1440
|
|
Main Stream:
|
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 24fps (2560 × 1440), 30fps (2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub Stream:
|
50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)
|
|
Third Stream:
|
50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Video Compression:
|
Main Stream: H.265+/H.265/H.264+/H.264
|
|
Sub-Stream: H.265/H.264/MJPEG
|
|
Third Stream: H.265/H.264/MJPEG
|
|
ROI encoding:
|
Support 2 areas with adjustable levels
|
|
Audio Compression:
|
G.711ulaw/G.711alaw/G.726/MP2L2/G.722
|
|
Audio Mode:
|
OFF/Audio input/Audio output
|
|
Protocols:
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
|
No. of Simultaneous Users:
|
Up to 20 users
|
|
Three-Stream:
|
Support
|
|
Mini SD Card:
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
|
|
User/Host Level:
|
Up to 32 users, 3 levels: Administrator, Operator and User
|
|
Security Measures:
|
User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering
|
|
Hik-Connect:
|
Support
|
|
General
|
|
Power Supply:
|
12 VDC & PoE
|
|
Power Consumption:
|
Max.: 12 W (Max. 3.9 W for IR)
|
|
Working Temperature/Humidity:
|
-20°C to 60°C (-4°F to 140°F)
|
|
Protection Level:
|
IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
|
Material:
|
Aluminum alloy, PC, PC+ABS
|
|
Dimensions:
|
Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00")
|
|
Weight (approx.):
|
Approx. 0.53 kg (1.17 lb)
|
