▶ 8MP IP HD Night Vision Bullet Camera: High quality imaging with 8 MP resolution
▶ Excellent low-light performance with
▶ powered-by-DarkFighter technology
▶ Clear imaging against strong back light due to 120 dB true WDR technology
▶ Efficient H.265+ compression technology
▶ Focus on human and vehicle targets classification based on deep learning
▶ Active strobe light and audio alarm to warn intruders off
▶ Provides real-time security via built-in two-way audio
▶ Water and dust resistant (IP67)
8MP Ultra HD resolution
Outputs max. 8MP , real monitoring scene, ultimate clarity images quality, good low illumination effect, providing the smoother video, and bring you higher definition and more details, which is 4 times the resolution of full HD 1080P.
How do i connect the camera
There are many ways to connect the camera, it can be directly connected through a DC12V power supply, or it can be connected through an NVR, router or switch, etc.
Infrared camera，Clear Night Vision
Home outdoor camera equipped with infrared lights for IR detection that provides clear images up to 30m away.It can automatically switch to black-white night vision, capture every movement in low light.
Two Way Audio ( Built-in mic/speaker)
Built in responsive microphone on the camera, you can listen and talk via App.
Whether courier parcels are often lost? Are you worried that strangers are threatening to approach your house? IP outdoor camera can save you from these troubles, Security camera will detect motion and push you notifications, then you can watch live video and talk to courier or stranger, Tell him where to put the courier, Prohibit access to your house.
IP67 Protection
Mount your camera outside against harsh environments with IP67 weather proof and mental housing to Withdstand vandalism.
VCA Detection - Video Content AnalysisCamera
Provides (Smart Event) LineCrossing / Intrusion Detection detection features which are based on the LTS DVR / LTS IP Camera function itself. The NVR can link the action with the LTS IP Camera.
Day/Night auto IR Cut Filter switch
With ICR day/night auto ir-cut filter switch, improve the sensitivity of the camera in low illumination scene effectively, to provid 24h real and clear live time image. Also built-in ir lens that offer up to 98ft ir night vision range. And Smart IR can control the intensity of infrared light to prevent the picture from being too bright or too dim.
H.265 Encoding
High Efficient encoding technology greatly saves bandwidth resource and storage space. Better encoding algorithm to save more bandwidth and storage.
120 dB True WDR & 3D DNR
* The true WDR ensures even ilumination for all areas of an image and balances the lighting to produce sharper videos.
* Eliminate the image noise day night greatly with the 3D DNR for clean images and save the video storage space
Multiple Storage
Mobile Remote Access
Easy to add the camera to mobile phone via IVMS4200, HIK-Connect Free APP, video surveillance is a total breeze. You can enjoy live video, play back, take snapshots, receive motion alarms anytime from anywhere. You can also share the device’s live video with your families and friends.
| Camera | |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Min. Illumination | Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| P/N | P/N |
| Wide Dynamic Range | 120 dB |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
| Iris Type | Fixed |
| Focal Length & FOV | 2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131° |
| 4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° | |
| 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60° | |
| Aperture | F1.6 |
| Lens Mount | M12 |
| DORI | |
| DORI | 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m |
| 4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m | |
| 6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m | |
| Illuminator | |
| Supplement Light Type | IR |
| IR Range | Up to 60 m |
| IR Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Visual Alarm | Yes |
| Video | |
| Max. Resolution | 3840 × 2160 |
| Main Stream | 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| 60 Hz: 24 fps (3840 × 2160) | |
| 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) | |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) |
| 60 Hz: 30 fps (640 × 480, 640 × 360) | |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) | |
| *Third stream is supported under certain settings. | |
| Video Compression | Main stream: H.265/H.264/H.264+/H.265+ |
| Sub-stream: H.265/H.264/MJPEG | |
| Third stream: H.265/H.264 | |
| *Third stream is supported under certain settings. | |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio | |
| Audio Type | Mono sound |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
| Network | |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, |
| IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP | |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, |
| Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE | |
| and digest authentication for Open Network Video Interface | |
| Network Storage | MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Together with high-end Hikvision memory card, memory card encryption and health detection are supported. | |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10+ |
| Plug-in free live view: Chrome 57.0+, Firefox 52.0+ | |
| Local service: Chrome 57.0+, Firefox 52.0+ | |
| Image | |
| SNR | ≥ 52 dB |
| Target Cropping | Yes |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Interface | |
| Alarm | 1 input, 1 output (max. 24 VDC/24 VAC, 1 A) |
| Audio | 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: |
| 2.2KΩ, interface type: non-equilibrium; | |
| 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output | |
| impedance: 100 Ω, interface type: non-equilibrium | |
| Built-in Speaker | Power: 2 W. Max. sound pressure level: 10 cm: 97 dB |
| Built-in Microphone | Yes |
| On-Board Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset | Yes |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Event | |
| Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm,exception |
| Smart Event | Scene change detection |
| Deep Learning Function | |
| Face Capture | Yes |
| Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
| Supports human and vehicle targets classification | |
| General | |
| Linkage Method | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning, strobe light |
| Web Client Language | 33 languages |
| English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, | |
| French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, | |
| Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, | |
| Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian | |
| General Function | Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Software Reset | Yes |
| Firmware Version | V5.5.112 |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, reverse polarity protection |
| PoE: 802.3af, Class 3 | |
| Power Consumption and Current | 12 VDC, 0.88 A, max. 10.5 W |
| PoE (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12.5 W | |
| Power Interface | Ø 5.5 mm coaxial power plug |
| Camera Material | Metal |
| Camera Dimension | Ø 105 mm × 287.6 mm (Ø 4.1" × 11.3") |
| Package Dimension | 386 mm × 156 mm × 155 mm (15.2" × 7.5" × 7.1") |
| Camera Weight | Approx. 1130 g (2.5 lb.) |
| With Package Weight | Approx. 1654 g (3.6 lb.) |
| Approval | |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN |
| 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC | |
| (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) | |
| Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529-2013) |
