| Camera |
| Image Sensor |
1/2.8”Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @(F1.0, AGC ON),0 Lux with Light |
| White Balance |
Auto/Manual |
| Shutter Speed |
1/10 s to 1/10,000 s |
| Day & Night |
24/7 hours full color |
| Digital Noise Reduction |
2D/3D DNR |
| WDR |
Support |
| Privacy Mask |
4 programmable privacy masks |
| Lens |
| Focal Length |
2.8 mm (3.6mm Optional) |
| Field of View |
Horizontal field of view: 103°
Vertical field of view: 59°
Diagonal field of view: 118° |
| Compression Standard |
| Video Compression |
Main stream: H.265+,H.265,H.264
Sub-stream: H.265+,H.265,H.264 |
| H.265 Type |
Baseline profile/Main profile/High profile |
| H.265+ |
Yes |
| Event |
| Basic Event |
Motion Detection |
| Intelligent detection |
Human Detection |
| Illuminator |
| Light Range |
30 m |
| LEDS |
2PCS Warm Light LED |
| Image |
| Max. Resolution |
3840 x 2160 |
| Main Stream |
20fps@8MP(3840 x 2160) 30fps@ (3072 x2048,2592 x1944,2560 x 1440,1920 x 1080) |
| Sub-Stream |
30fps@720 x480 /VGA/640x360/480 x360 /CIF |
| Image Enhancement |
BLC/3D DNR/HLC/WDR |
| Network |
| Network Storage |
Support Local storage and NFS,NVR,APP Cloud Storage |
| Protocols |
TCP/IP/IPv4/IPv6/HTTP/RTSP/NFS/DHCP/NTP/SMTP/FTP/SSL |
| General Fuction |
Built-in Mic,Privacy Masks, Horizon/Vertical Flip,Password Reset,Upgrade |
| API |
ONVIF (Profile S, Profile G, Profile T) |
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
3 levels: Administrators, Operators and Users |
| Client |
AjDevTool,SADP, Danale App,LMS,iVMS-4200 |
| Web Browser |
IE 8+ ,Chrome 57.0+, Firefox 52.0+ |
| Interface |
| Network Interface |
1 RJ45 10 M/100 M Ethernet, PoE |
| Power |
12V DC |
| Audio IN |
Built-in Mic |
| Audio Out |
N/A |
| RS485 |
N/A |
| SD Card slot |
N/A |
| General |
| Web Client Language |
7 languages:
Chinese, English, Russian, German, Italian, , Turkish, 한국어 |
| Power |
12V DC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR)
PoE (802.3af), 36 to 57V DC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR) |
| Working Environment |
Temperature: -20°C to 60°C (-4°F to 140°F), humidity: ≤ 90% |
| Protection Level |
IP67 |
| Material |
Metal |
| Dimension |
Package: 140 x 135 x 115 mm (5.5'' x 5.3'' x 4.5'') |
| Weight |
With Package : Approx. 0.53 kg (1.16 lb.) |
