| Camera |
|
| Image Sensor |
1/2.5" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| P/N |
P/N |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Lens |
|
| Lens Type & FOV |
2.8 mm, horizontal FOV 102°, vertical FOV 53°, diagonal FOV 123° |
| Aperture |
F2.0 |
| Lens Mount |
M12 |
| Illuminator |
|
| IR Range |
Up to 30 m |
| Wavelength |
850 nm |
| Smart Supplement Light |
Yes |
| Video |
|
| Max. Resolution |
3840 × 2160 |
| Main Stream |
50 Hz: 12.5 fps (3840 × 2160, 2592*1944，2688 × 1520, 1920 × 1080, 1280 × 720) |
|
60 Hz: 15 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50 Hz: 25 fps (640 × 480, 640 × 360) |
|
60 Hz: 30 fps (640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265+/H.265 |
|
Sub-stream: H.265/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.265 Type |
Main Profile |
| H.265+ |
Main stream supports |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
H.265 supports |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Audio |
|
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz |
| Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Network |
|
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (PROFILE S, PROFILE G), ISAPI, SDK, ISUP |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP, 802.1x, SSL/TLS, PPPoE |
| User/Host |
Up to 32 users |
|
3 levels: Administrator, Operator and User |
| Network Storage |
Supports microSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
Plug-in required live view: IE 10, IE 11 |
|
Local service: Chrome 57.0+, Firefox 52.0+ |
| Image |
|
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Settings |
Mirror, saturation, brightness, contrast, sharpness, AGC, and white balance ajustable by client sfotware or web browser |
| Privacy Mask |
4 regions of privacy masks |
| Interface |
|
| Built-in Microphone |
Yes |
| On-board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Smart Feature-Set |
|
| Basic Event |
Motion detection(support alarm triggering by specified target types (human and vehicle)), video tampering, exception |
| General |
|
| Linkage Method |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture |
| Firmware Version |
V5.5.104 |
| Web Client Language |
33 languages |
|
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Anti-flicker, heartbeat, password protection, password reset via email |
| Software Reset |
Yes |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25% |
|
PoE: 802.3af, Type 1 Class 3 |
| Power Consumption and Current |
12 VDC, 0.4 A, max. 5 W |
|
PoE (802.3af, 36 V to 57 V), 0.20 A to 0.1 A, max. 6.5 W |
| Power Interface |
Ø5.5 mm coaxial power plug |
| Camera Material |
Aluminum alloy body |
| Camera Dimension |
Ø110 mm × 81.25 mm (Ø4.33" × 3.20") |
| Package Dimension |
150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
| Camera Weight |
Approx. 390 g (0.9 lb.) |
| With Package Weight |
Approx. 656 g (1.4 lb.) |
| Approval |
|
| EMC |
FCC SDoC (47 CFR Part 15, Subpart B); |
|
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); |
|
RCM (AS/NZS CISPR 32: 2015); |
|
IC VoC (ICES-003: Issue 6, 2016); |
|
KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); |
|
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); |
|
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); |
|
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); |
|
LOA (IEC/EN 60950-1) |
| Environment |
CE-RoHS (2011/65/EU) |
|
WEEE (2012/19/EU) |
|
Reach (Regulation (EC) No 1907/2006) |
| Protection |
IP67 (IEC 60529-2013) |
